JBL AM7215/26 - 15-inch Two-Way Full Range Loudspeaker with 120 deg x 60 deg Rotatable Horn

JBL AM7215/26 - 15-inch Two-Way Full Range Loudspeaker with 120 deg x 60 deg Rotatable Horn

EAW
SKU:
AM7215/26
$3,935.00
Current Stock:
Description

JBL AM7215/26 - 15-inch Two-Way Full Range Loudspeaker with 120 deg x 60 deg Rotatable Horn

The AM7215 speakers are high power, lightweight, 2-way, full-range loudspeaker systems comprised of the JBL Differential Drive dual voice coil and dual magnetic gap 2265H 380 mm (15 in) low-frequency driver and 2432H high-frequency 38 mm (1.5 in) exit, 75 mm (3 in) voice-coil compression driver. The large format Progressive Transition waveguide provides excellent coverage. The waveguide is rotatable so the loudspeaker system can be used in either the vertical or horizontal orientation. High-slope passive networks minimize band overlap. Well-controlled off-axis response enhances arrayability.

Features

  • 120° x 60° Coverage
  • 2265H Differential Drive® Low- Frequency Driver
  • 2432H High-Frequency Compression Driver
  • Large PT™ Progressive Transition waveguide for excellent pattern control and low distortion
  • Rotatable waveguide for vertical or horizontal orientation
  • Bi-Amp/Passive Switchable
  • Bi-amp and Passive Mode FIR Tuning Set Delivers Optimized Frequency & Phase Response, Coverage Consistency, and Sound Quality
  • Available in Black, White and WRC/WRX finishes


Applications

  • Performing Arts Facilities
  • Theatrical Sound Design
  • Auditoriums
  • Worship Facilities
  • Live Clubs
  • Dance Clubs
  • Sports Facilities
  • Themed Entertainment Venues

Specifications


Frequency Range (-10dB) 53 Hz - 20 kHz
Frequency Response (±3 dB) 65 Hz – 20 kHz
System Power Rating 700 W (AES rated)
375 W / 750 W / 1500 W (Continuous/Program/Peak) (IEC rated)
Impedance 8 ohms
Coverage Pattern /26: 120° x 60°/95: 90° x 50°
Dimensions (H x W x D) 679.5 x 237.5 x 254.0 mm (26.8 x 9.4 x 10.0 in)
Net Weight (each) Frequency Range (-10dB) 34 Hz - 20 kHz
Crossover Modes Frequency Response (±3 dB) 40 Hz - 18 kHz
Maximum SPL (1m) Coverage /64: 60° x 40°/66: 60° x 60° /95: 90° x 50° /26: 120° x 60°
System Sensitivity (1w @ 1m) LF Driver 1 x JBL 2265H 380 mm (15 in) Differential Drive® driver with 75 mm (3 in) dual voice coil
LF Driver HF Driver JBL 2432H, 38 mm (1.5 in) exit compression driver, 75 mm (3 in) voice coil
Nominal LF Driver Impedance System Type 15" Two - Way, High Power, Full - Range
HF Driver Dimensions (H x W x D) 781 x 420 x 503 mm (30.8 x 16.5 x 19.8 in)
Enclosure Net Weight (each) 27.2 kg (60 lb)
Suspension Attachment Crossover Modes Bi-amp/Passive switchable
Environmental Passive Crossover Frequency 1.8 kHz
  Transducer Power Rating (AES) LF: 1000 W (4000 W peak), 2 hr750 W (3000 W peak), 100 hrsHF: 100 W (400 W peak), 2 hrs
  System Power Rating Passive mode: 600 W (2400 W peak), 100 hrs
  Maximum SPL (1m) Bi-amp mode:LF: 128 dB-SPL cont avg (134 dB peak)HF: 135 dB-SPL cont avg (141 dB peak)Passive mode:124 dB-SPL cont avg (130 dB peak)
  System Sensitivity (1w @ 1m) Passive mode: 96 dB SPL
  Nominal Impedance 8 ohms
  System Power Rating Passive mode: 600 W (2400 W peak), 100 hrs (IEC rated)
  Nominal LF Driver Impedance 8 ohms
  Nominal HF Driver Impedance 8 ohms
  Enclosure Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply Finnish birch plywood
  Suspension Attachment 15 points (4 top, 4 bottom, 2 each side, 3 rear), M10 threaded hardware
  Environmental Mil-Std 810; IP-x3 per IEC529.
